Swiss made - Performance - Precision - Quality

Digital Electronic High-Power Programmable Power Supplies

REGATRON's New Generation of Programmable Regenerative DC Power Supplies Is Now Available Driving Vehicle Electrification Forward with REGATRON’s New Drivetrain Tester Series

Energizing the Future with REGATRON's New Battery Tester Series

The new G5.RSS series features high control dynamics, an exceptional accuracy, a nominal output voltage of up to 3000 VDC, and a wide current-voltage range with an auto-ranging factor of 3. You get the best value for your investment.

The modular and finely graded G5.RSS series is bidirectional regenerative and can operate in CV, CC, CP, CR, and Ri-Sim control modes. It is universally applicable and therefore suitable for all industrial and scientific applications in laboratories as well as on test benches and production lines. Adjustable filter time constants, optional software, programming and communication interfaces as well as safety functions allow the G5.RSS power supplies to be optimally adapted to the customer application requirements.

Modular and Easy Scalable Systems
The output of an individual power supply is in the range from 0...18 kW to 0...2000+ kW, up to 3000 VDC. The advantageous modularity of REGATRON power supply solutions allows the system to be easily adapted to ever changing test requirements. Not only is it possible to reconfigure between parallel, series, and mixed operation, but also to expand the system with additional power supply units or to split it into smaller units. Therefore, the purchase of a REGATRON power supply is a solid investment for the future.

Features
Adjustable controller settings and the integrated 8-channel digital scope assist the user to easily achieve optimal system behavior. The G5.RSS series offers the possibility to store, edit, and recall any device configuration on board the power supply.

Technology
• Technologically advanced, fast switching, compact 19-inch power supplies

•High control dynamics in the 100...200 µs range – even at higher power levels
•Exceptional current accuracy of <0.02% FS, additional high-resolution current measurement range
•Wide current-voltage range with an auto-ranging factor of 3
•CV, CC, CP, CR, and Ri-Sim control modes
•Regenerative and highly efficient, resulting in significant reduction of energy consumption and heat dissipation

System Capability
•Modular and easily scalable systems
•Parallel, series, and mixed operation with a digital high-speed bus
•Simple master-slave configuration with the operating software
•Turn-key cabinet solutions up to IP54 or project-specific system integration according to customer specification
• Optional safety features such as 2-channel safety interface and insulation monitoring

•Optional third party product integration, AC/DC connectors, and cables that allow comfortable handling

System Control and Options
•Operating software: extended analysis, parameterization options, and calibration
•Powerful application programming interfaces APIs
•Optional front-panel-integrated control unit HMI with touch screen
•Optional CAN multi-protocol interface with 1 kHz data rate and 16-bit resolution

Developing and testing the powertrain and its components plays a key role in the design of hybrid and electric vehicles. Test systems for electric drive components or even for the complete drivetrain must offer a wide range of functions, exceptional dynamics and comprehensive safety features. In many cases, an easy integration of the test systems into an existing control platform is a prerequisite. Frequently changing test conditions require a high degree of flexibility in terms of power, voltage and current. In addition, workplace safety regulations require the ability to quickly and easily bring a running system to a safe state in case of an emergency.

Modular and Easy Scalable System
The output of an individual G5.DT Drivetrain Test System is in the range from 0...18 kW to 0...2000+ kW, up to 1500 VDC. Higher voltages are available on request. The advantageous modularity of REGATRON power supply solutions allows the system to be easily adapted to ever changing test requirements. Not only is it possible to reconfigure between parallel, series, and mixed operation, but also to expand the system with additional power supply units or to split it into smaller units. Therefore, the purchase of a REGATRON Drive Train Tester is a solid investment for the future.

Technology and Exceptional Features

•Technologically advanced, fast switching, compact 19-inch power supplies
•Current accuracy of <0.02% FS, additional high-resolution current measurement range
•Voltage accuracy of 0.01% FS
•Current rise time in the 50...200 µs range – even at higher power levels
•Wide current-voltage range with an auto-ranging factor of 3
CV, CC, CP, CR, and Ri-Sim control modes
•Full power regeneration and a high degree of efficiency, resulting in significant reduction of energy consumption and heat dissipation

System Capability
•Parallel, series, and mixed operation with a digital high-speed bus
•Simple master-slave configuration with the operating software
•Turn-key cabinet solutions up to IP54 or project-specific system integration according to customer specification
•Integrated safety relay ISR for increased emergency stop reliability supporting performance level PL e according to EN ISO 13849

System Control and Options
Operating software: extended analysis, parameterization options, and calibration
CAN multi-protocol interface with 1 kHz data rate and 16-bit resolution
Powerful application programming interface API
Front-panel-integrated control unit HMI with touch screen
Switch-selectable setting of parallel and series configuration*
Real-time Insulation monitoring*
Automatic Active DC Energy shut-down in an emergency*
*Optional

REGATRON's regenerative bidirectional G5.BT Battery Test System is safe, reliable, and modular. It features an exceptional current accuracy of <0.02% FS, an additional high-resolution current measurement range, and a fast current rise time in the 100 µs range.

Working with high-power batteries is very demanding. Voltages, currents and temperatures must be monitored and kept within a safe range. In addition, connecting a battery to a load or battery tester also requires appropriate attention to polarity and voltage levels. Today's batteries are no longer simple battery cell stacks, but complex modules with superposed power electronics that require highly accurate data acquisition and fast response times.

Technology and Exceptional Features

•Technologically advanced, fast switching, compact 19-inch power supplies
•Current accuracy of <0.02% FS, additional high-resolution current measurement range
•Voltage accuracy of 0.01% FS
•Current rise time in the 50...200 µs range – even at higher power levels
•Detection of reverse polarity connection, avoiding sparks, fire, welding, and other damages to battery and battery tester
•Overcurrent protection in case of unmatched voltages between battery and tester
•Avoidance of deep battery discharge at 'Voltage Off' state
•Current ripple modulation up to 10 kHz
•Wide current-voltage range with an auto-ranging factor of 3
CV, CC, CP, CR, and Ri-Sim control modes
•Power regeneration and a high degree of efficiency, resulting in significant reduction of energy consumption and heat dissipation

System Capability
•Parallel, series, and mixed operation with a digital high-speed bus
•Simple master-slave configuration with the operating software
•Turn-key cabinet solutions up to IP54 or project-specific system integration according to customer specification
•Integrated safety relay ISR for increased emergency stop reliability supporting performance level PL c / PL e according to EN ISO 13849

System Control and Options
Operating software: extended analysis, parameterization options, and calibration
CAN multi-protocol interface with 1 kHz data rate and 16-bit resolution
Powerful application programming interfaces APIs
Application software BatControl with visualization, parameterization, programming, and data logger
Front-panel-integrated control unit HMI with touch screen
Switch-selectable setting of parallel and series configuration
Insulation monitoring


AC Grid Simulators

Software Driven AC and DC High Power Systems

Programmable DC Power
0...52 VDC up to 0...1200 VDC
10, 16, 20 and 32 kW

Grid simulator systems use a top-of-the-art
multilevel double inverter technology
full 4-quadrant operation

TopCon TC.ACS
bidirectional three-phase grid simulator
Grid simulation software



REGATRON regenerative systems allow for the outermost freedom in system design due to separate feeding and regenerative system parts


TC.ACS grid simulators can perform EMC tests
as per CENELEC IEC 61000-4-14, IEC 61000-4-27 and IEC 61000-4-28


Special DC supplies which can both feed and absorb energy. TopCon RESACT:
Bidirectional DC supplies + electronic load

Regatron AG Products

Active for 50 years in the electronics manufacturing, Regatron AG has earned a remarkable experience in manufacturing high-quality modular programmable power supplies, and is appreciated by many world leaders who use TopCon in their factories or laboratories or research and development centers.

Products & Solutions
Programmable Power Supplies
Automation: Customer specific Industrial Electronics
Motion Control: Servo Systems and Frequency Converters
Mechanical Drive Elements: Motors and Gears

Fields of Application
Manufacturing and Tooling Technology
Plastics Industry
Textile Industry
Medical Applications
Rail Technology
Test and Lab Technology

MasTec Ltd is very pleased to be able to handle these products for the NZ market.

The Swiss company Regatron AG designs, manufactures and sells digital electronic high-power programmable power supplies, intended for professional applications, and supports its customers both in the choice of the most appropriate solutions, both in the supply of know-how, specialized software, cabinets and systems, accessories, optional parts and technical support remotely or at the client location.

AC /DC programmable digital high power, battery emulators, grid simulators, three-phase AC/DC power supplies for bidirectional testing and simulation of batteries, amplifiers, precision linear simulators for photovoltaic inverters, AC sources: a production of excellence spread all over the world.

Heavier environmental conditions than laboratory? Mobile? Marine? Submarine? Military or other harsh conditions?

Throughout the last 20 years, REGATRON has delivered a large number of rugged programmable DC power supplies for highly demanding applications including marine, submarine, offshore, military, aerospace / satellites, utility vehicles and railway.

Examples of applied standards: IEC 60068-2-6, IEC 60068-2-64, IEC 60068-2-27, IEC 60068-2-78, IEC 60721-4-2, MIL STD-810G, DEF STAN 00-35, MIL STD 901D, MIL STD 167-1A.


Talk to our MasTec's Sales Engineer

DC Power Supplies with modern grid-tie inverter technology in order to handle both current flows
from and towards the load.

Replace a real fuel cell by an electronic power source able to handle the energy flow
fuel cell simulation software



Replace a real battery power pack by an
electronic power source
able to handle both energy flow directions



integrated current-bidirectional power sources
DC power supplies + modern grid-tie inverter
handle both current flows from and towards the load.


756kW Q1 power system, consisting of 6 racks with 4x32kW TopCon devices each.
Unidirectional Q1 DC Source


50 kW / 125 A discharge unit to completely discharge batteries (during the recycling process
Unidirectional Q4 DC Sink
Sophisicated DC and AC Power Supplies

Very High Power Power Systems
